A CNN Approach for Recognizing Traffic Signs

A CNN Approach for Recognizing Traffic Signs

Deep Learning is an interesting and a unique field of study that has attracted the worldwide attention over the past few years at a rapid pace. The rate at which the digitalized systems have been generating data for over a decade, has become one of the major reasons for creating an abundance of data. As a result, the availability of data provided a brand new perspective for the researchers to look at Artificial Intelligence and its branches, in a different way. Additionally, the gradual enhancement of hardware resources resulted in offering much improved computational resources for the deep learning researchers to make use of data efficiently. Therefore, the combination of data and modern computational resources, was able to create a platform for the researchers to thrive on, and the result is a highly motivated deep learning community that continues to contribute towards the growth of deep learning using novel approaches. Computer vision is a research area that has benefitted largely from the rise of deep learning, and it is evident from the amount of research studies carried out in computer vision with deep learning.

While there are many specific applications of computer vision, the uses of deep learning in traffic/road related applications, is an interesting application since it directly affects the improvement of vehicular automation. Although the field of vehicular automation is on the verge of reaching greater heights, as evident from Tesla’s Autopilot feature (and similar implementations from other major automobile manufacturers), understanding the fundamentals of deep learning remains an integral part for those who are interested in exploring the capabilities of deep learning. In this article, we focus on bringing you a primer for understanding how the nuts and bolts of deep learning can effectively improve the metrics that measure the success of a specific application that targets traffic signs. Thus, our attempt is to explore the process of developing a traffic sign recognizer using the concepts of deep learning.

We have structured the article in way that allows you to easily move to the desired section with ease. Initially, we explain the Background behind the problem before coming up with an Exploratory Data Analysis for the dataset which we utilized. Afterwards, the Deep Learning Workflow provides a high-level overview of the procedure followed by us, and then we place our emphasis on creating a suitable Input Pipeline for preparing the data to meet the requirements of the Models explained in the subsequent section. Finally, we examine the performance of the developed model, before capping the article off by deploying it as a readymade model which can be tested by yourself using an interactive interface. Sounds interesting, huh?

Background

The Problem

A brief writeup on the actual problem that we are attempting to address. In our context, the broader problem is to check the possibility of recognizing the traffic signs via the concepts of computer vision.

What will straightly come to your mind if you are asked to think of a main road in any part of the world? Obviously, the pedestrians and vehicles should greet your mind as they make the roads busy, thanks to the continuous movements made by them. The clutters of vehicles and pedestrians can certainly lead to unpleasant outcomes, and as a result, standardized road rules have been set up by the authorities to minimize the clutters and to streamline the traffics in a structured manner. Since the drivers and pedestrians are supposed to obey the rules, having assistive signs/lights can definitely help both the drivers and pedestrians to ensure that the road is a safe environment for everyone.

This is where the importance of traffic signs, comes into the frame to act as guidelines for both drivers and pedestrians. While the traffic signs are supposed to be understood by human vision, it is interesting to if the same phenomenon can be emulated using computer vision. In this article, we attempt to address a basic problem, in which we check the possibility of recognizing the traffic signs via the concepts of computer vision.

The Aim (and objectives)

In a broader context, our aim is to develop a recognizer that correctly classifies a given traffic sign image to determine its class, using the concepts of deep learning in computer vision. It is expected to achieve the aim by methodically following the objectives given below.

  1. Exploring the health of the dataset by performing an Exploratory Data Analysis
  2. Preprocessing the data for building the input pipeline
  3. Defining a suitable methodology that iteratively improves the performance of the model.
  4. Testing the performances on unseen datasets.
  5. Developing a tool for allowing the user to self-test the capabilities of the developed model.

The Dataset

As we explained in the Introduction section, datasets play a pivotal role in the development of a deep learning based solution. Fortunately, there are freely available datasets for achieving our requirement. Therefore, we used the German Traffic Sign Recognition Benchmark (GTSRB) dataset provided by the Institut für Neuroinformatik. The dataset has been initially provided as a multi-class classification challenge at the International Joint Conference on Neural Networks (IJCNN) 2011.

Exploratory Data Analysis

The Exploratory Data Analysis (EDA) is a common component that provides a representation of the original dataset using descriptive statistical methods with the aid of relevant plots. For more information, refer the following link:
What is Exploratory Data Analysis?

Once we downloaded the ZIP file from the source given above, we came across datasets corresponding to three distinct categories inside the ZIP archive: Train, Test, and Meta. The images related to the Train dataset were stored inside the Train folder where separate sub-folders had been created to organize the Train images under different class labels. In contrast, the images related to the Test dataset were directly inside a folder named Test. The Meta folder was composed of computer-illustrated images to represent each class label and few of the images from all three categories are given below. Additionally, the archive contained three annotated Comma Separated Files (CSV) named Train.csv, Test.csv, and Meta.csv. The composition of each CSV file, is further discussed within this section in the following paragraphs.

Train

Sample Image from the Dataset

Number of Images

In order to explore the number of available images in the Train dataset, the Train.csv file can be analyzed. The Pandas library in Python is a useful tool for dealing with CSV files by including the data into a Dataframe. Based on the results, the dataset contained 39,209 images.

Number of Classes

The dataset consists of images corresponding to 43 classes, numbered sequentially from 0 to 42.

Class Distribution

The following figure represents the class distribution of the Train dataset.

Structure of Data

Altogether, the Train.csv file contains the following list of important fields which can be utilized as per the requirements [Ref: German Traffic Sign Benchmarks ]

  • Width: The width of the image in pixels
  • Height: The width of the image in pixels
  • Roi.X1: The X-coordinate of top-left corner of traffic sign bounding box
  • Roi.Y1: The Y-coordinate of top-left corner of traffic sign bounding box
  • Roi.X2: The X-coordinate of bottom-right corner of traffic sign bounding box
  • Roi.Y2: The Y-coordinate of bottom-right corner of traffic sign bounding box
  • ClassId: The actual class label

Test

The annotated file for the Test dataset (Test.csv) also follows a layout similar to the Train.csv.

Sample Images from the Dataset

Number of Images

The Test dataset consists of 12,630 images as per the actual images in the Test folder and as per the annotated Test.csv file.

Number of Classes

As expected, The Test dataset also consists of images corresponding to 43 classes, numbered sequentially from 0 to 42.

Class Distribution

The following figure represents the class distribution of the Test dataset.

Meta

Sample Images from the Meta Dataset

The Meta Dataset, along with the Meta.csv has been provided as a guideline to represent the actual images and the related Class labels.

The Deep Learning Workflow

Here, we will add a high level diagram for explaining the iterative workflow that we follow throughout the model development/improvement process. The diagram will represent the usual Machine/Deep Learning workflow, with specific customizations to cater the expected outcomes of our case study.

Over the years, the machine learning community has adopted a certain workflow that keeps them in the hunt for the reaching the desired aims and objectives. The following figure depicts the workflow which we usually follow in the process of developing machine/deep learning applications. In reality, deep learning is a highly iterative process that requires the developers to keep experimenting until the target objectives are achieved.

The Deep Learning Workflow

As shown in the above figure, once we have a dataset which is suitable to be applied for a deep learning task, the dataset is usually split into three subsets, known as Training Dataset, Validation Dataset and Test Dataset. The splitting process may vary, depending on the original dataset that you have, and in the context of GTSRB dataset, the authors had provided both the Training Dataset and Test Dataset separately. Since the Validation Dataset is not available in GTSRB dataset, it is up to the developers to decide the best possible way forward for creating a Validation dataset, depending on the application.

Once the Train/Validation/Test split is finalized, the Training Dataset is utilized for training the initial model, as shown in Step (2). The creation of the model initiates the iterative cycle where the model is tested against the Validation dataset to obtain the necessary evaluation metric. Based on the result of the evaluation metric, the developers are supposed to keep on experimenting and form a new model and follow the same cycle, until a model with a viable evaluation metric result is obtained. After the finalization of a model, it is considered as the Acceptable Model [Step (4)]. The Test Dataset consists of real-world data that the model has not previously seen and it provides us the opportunity to Test the created model against real-world data to actually see how it would eventually perform on the production run.

The Input Pipeline

In this section, the focus will be placed on the explaining the preprocessing steps which we followed, before the development of models.
For instance, the process of preparing Train/Validation/Test/StreetViewTest datasets, is explained, along with the other normalization steps taken during the process

In this section, we focus on the preparation of our original datasets according to a standard formats used in the process of practicing deep learning. Therefore, the preparation of the input pipeline can be illustrated in two separate steps where the first step is to prepare Training, Validation and Test datasets from the originally available data. Subsequently, we dive into the additional task of normalizing the inputs before sending them through the training cycle.

Initialization

Since this is the beginning of the code, first of all, it is required to import the necessary libraries which are required throughout the implementation.

import numpy as np
import pandas as pd
import matplotlib.pyplot as plt
import cv2
import tensorflow as tf
from PIL import Image
import keras
import os
from sklearn.model_selection import train_test_split
from tensorflow.python.keras import regularizers

Usually, when we deal with images, we deal with the array representations of the respective images, rather than working with the usually known JPEG or PNG (or any other image format) formats. The following code snippet shows how we load and convert the images to arrays from the originally available Train and Test image datasets. In the conversion job, we also place emphasis on making all the observations have the same shape when it comes to the representation of resolution of each observation. Therefore, each image is resized to have a resolution of 30x30 before being converted to a numpy array.

# Loading the Train Dataset
train_data = []
train_labels = []
basedir = "../Datasets/gtsrb"
classes = 43

for i in range(classes):
    path = os.path.join(basedir,'train',str(i))
    images = os.listdir(path)

    for j in images:
        print("Class: " + str(i) + " - Image: " + str(j))
        image = Image.open(path + '\\'+ j)
        image = image.resize((30,30))
        image = np.array(image)
        train_data.append(image)
        train_labels.append(i)

train_data = np.array(train_data)
train_labels = np.array(train_labels)

# Loading the Test Dataset

image_paths = []
test_data=[]
test_file_path = os.path.join(basedir, 'Test.csv')

Y_test_df = pd.read_csv(test_file_path)
Y_test_orig = Y_test_df["ClassId"].values

for short_path in Y_test_df["Path"]:
    image_paths.append(os.path.join(basedir, short_path))

for img in image_paths:
    print("Path: " + str(img))
    image = Image.open(img)
    image = image.resize((30,30))
    test_data.append(np.array(image))

X_test_orig = np.array(test_data)

In order to be used later for evaluation purposes, we created a custom traffic sign dataset from the images captured from Google Street View as well. The following code snippet shows how we imported them by following a similar approach shown in the previous code snippets.

# Loading the Custom Street View Dataset
sv_test_image_paths = []
sv_test_data=[]
sv_test_file_path = os.path.join(basedir, 'StreetView.csv')

Y_sv_test_df = pd.read_csv(sv_test_file_path)
Y_sv_test_orig = Y_sv_test_df["ClassId"].values

for short_path in Y_sv_test_df["Path"]:
    sv_test_image_paths.append(os.path.join(basedir, short_path))

for img in sv_test_image_paths:
    print("Path: " + str(img))
    image = Image.open(img).convert('RGB')
    image = image.resize((30,30))
    sv_test_data.append(np.array(image))

X_sv_test_orig = np.array(sv_test_data)

Train/Validation/Test Datasets

Since the original dataset comes with two main datasets (Train and Test), it was up to us to prepare the Validation dataset from the available data. Therefore, it was decided to keep aside a portion of the Train dataset for Validation dataset, and as a result, 20% of the Train dataset was allocated for the Validation dataset. Alternatively, you may use k-fold Cross Validation instead of the approach followed by us here in this section. The parameter {{random_state}} controls how the shuffling is applied before the splitting process. Using the same value for random_state will ensure that the results of the split datasets are reproducible on future instances.

X_train_orig, X_val_orig, Y_train_orig, Y_val_orig = train_test_split(train_data, train_labels, test_size=0.2, random_state=68)

Usually, it is very important to keep track of the shapes of the dataset arrays used throughout the implementation. The code snippet given below, displays the shapes of numpy arrays, after the splitting process. The code snippet further shows the number of training examples in the Training and Validation datasets after the split.

print ("Number of Training Examples = " + str(X_train_orig.shape[0])) // 31367
print ("Number of Validation Examples = " + str(X_val_orig.shape[0])) // 7842
print("X_train_orig shape: " + str(X_train_orig.shape))               // (31367, 30, 30, 3)
print("Y_train_orig shape: " + str(Y_train_orig.shape))               // (31367,)
print("X_val_orig shape: " + str(X_val_orig.shape))                   // (7842, 30, 30, 3)
print("Y_val_orig shape: " + str(Y_val_orig.shape))                   // (7842,)
print("X_test_orig shape: " + str(X_test_orig.shape))                 // (12630, 30, 30, 3)
print("Y_test_orig shape: " + str(Y_test_orig.shape))                 // (12630,)
print("X_sv_test_orig shape: " + str(X_sv_test_orig.shape))           // (32, 30, 30, 3)
print("Y_sv_test_orig shape: " + str(Y_sv_test_orig.shape))           // (32,)

Normalizing Inputs

Normalizing is a common practice in deep learning as it helps in speeding up the training process considerably. The normalization process is applied to all the datasets, and in this case-study, we apply a very simple normalization approach where the intensity values from each pixel, are divided by 255. The value 255 is chosen as the divider because 255 is the maximum possible intensity value.

Normalize image vectors

# Normalize image vectors
X_train = X_train_orig/255
X_val = X_val_orig/255
X_test = X_test_orig/255
X_sv_test = X_sv_test_orig/255

One-Hot Encoding

In the datasets that we are currently dealing with, we have a categorical variable as the output (i.e. 43 classes for representing the output). While some algorithms are capable of dealing with categorical data, many of the algorithms are comfortable on dealing with numerical data instead of the categorical data. One-Hot Encoding is a conversion process for representing categorical data numerically. Imagine that we are developing an animal classifier and suppose that we have cat, dog, squirrel, and elephant as the set of types of animals (as shown in Table 1). Once the One-Hot Encoding is applied to the data given in Table 1, the output becomes a numerical representation as depicted in Table 2.

For One-Hot Encoding, we use the function given below.

def convert_to_one_hot(Y, C):
    Y = np.eye(C)[Y.reshape(-1)].T
    return Y

The following code snippet shows how we applied the One-Hot Encoding to data corresponding to the output (Y) from all the available datasets. The code snippet further shows shapes of the numpy arrays after all the previously followed steps.

Y_train = convert_to_one_hot(Y_train_orig, 43).T
Y_val = convert_to_one_hot(Y_val_orig, 43).T
Y_test = convert_to_one_hot(Y_test_orig, 43).T
Y_sv_test = convert_to_one_hot(Y_sv_test_orig, 43).T

print ("Number of Training Examples = " + str(X_train.shape[0]))  // 31367
print ("Number of Validation Examples = " + str(X_val.shape[0]))  // 7842
print ("Number of Test Examples = " + str(X_val.shape[0]))        // 12630
print("X_train shape: " + str(X_train.shape))                     // (31367, 30, 30, 3)
print("Y_train shape: " + str(Y_train.shape))                     // (31367, 43)
print("X_val shape: " + str(X_val.shape))                         // (7842, 30, 30, 3)
print("Y_val shape: " + str(Y_val.shape))                         // (7842, 43)
print("X_test shape: " + str(X_test.shape))                       // (12630, 30, 30, 3)
print("Y_test shape: " + str(Y_test.shape))                       // (12630, 43)
print("X_sv_test shape: " + str(X_sv_test.shape))                 // (32, 30, 30, 3)
print("Y_sv_test shape: " + str(Y_sv_test.shape))                 // (32, 43)

Array to Image

If you are curious, you can always convert an array representation of an image to an image, and see the how it actually looks like. The following code snippets show how you can convert an array back to an image.

Sample image from the Train dataset

# Sample image from the Train dataset # Sample image from Street View Sample
index = 36 index = 24
plt.imshow(X_train[index]) plt.imshow(X_sv_test[index])
print ("y = " + str(np.squeeze(Y_train_orig[index]))) print ("y = " + str(np.squeeze(Y_sv_test_orig[index])))

Setting up Commonly Used Functions

We realized that there are tasks that required us to follow almost the same procedure with slight adjustments to the code. From a programming perspective, this is an area where the usage of functions come in handy. We coded up three functions to encapsulate three tasks: 1) Training and Plotting; 2) Plotting; and 3) Evaluation

The following code snippet displays the code blocks used by us. Feel free to make adjustments wherever necessary.

Common Functions

def train_and_plot(model, epochs = 10, batch_size = 64):
    train_dataset = tf.data.Dataset.from_tensor_slices((X_train, Y_train)).batch(batch_size)
    val_dataset = tf.data.Dataset.from_tensor_slices((X_val, Y_val)).batch(batch_size )
    history = model.fit(train_dataset, epochs = epochs, validation_data=val_dataset)
    plot(history)

def plot(history):
    # Plotting the Accuracy variation
    plt.figure(0)
    plt.plot(history.history['accuracy'], label='Training Accuracy')
    plt.plot(history.history['val_accuracy'], label='Validation Accuracy')
    plt.title('Variation of Accuracy')
    plt.xlabel('Epochs')
    plt.ylabel('Accuracy')
    plt.legend()
    plt.show()
    # Plotting the Loss variation
    plt.figure(1)
    plt.plot(history.history['loss'], label='Training Loss')
    plt.plot(history.history['val_loss'], label='Validation Loss')
    plt.title('Loss')
    plt.xlabel('Epochs')
    plt.ylabel('Loss')
    plt.legend()
    plt.show()

def evaluate_validation(model, no_of_images, rows, columns, dataset_type):
    X_ds = None
    Y_ds = None
    Y_orig_ds = None
    result_title = None

    if dataset_type == 'test':
        X_ds = X_test
        Y_ds = Y_test
        Y_orig_ds = Y_test_orig
        result_title = "TEST"
    elif dataset_type == 'val':
        X_ds = X_val
        Y_ds = Y_val
        Y_orig_ds = Y_val_orig
        result_title = "VALIDATION"
    else:
        X_ds = X_sv_test
        Y_ds = Y_sv_test
        Y_orig_ds = Y_sv_test_orig
        result_title = "STREETVIEW TEST"

    eval_result = model.evaluate(X_ds, Y_ds)
    pred = model.predict(X_ds)
    pred_label = [np.argmax(x) for x in pred]

    plt.figure(figsize=(25, 25))
    for i in range(no_of_images):
        plt.subplot(rows, columns, i + 1)
        if (pred_label[i] == Y_orig_ds[i]):
            plt.title(str(pred_label[i]) + " - CORRECT")
        else:
            plt.title(str(pred_label[i]) + " - INCORRECT")
        plt.imshow(X_ds[i])
        plt.axis("off")
    plt.show()

    y_actu = pd.Series(Y_orig_ds, name='Actual')
    y_pred = pd.Series(pred_label, name='Predicted')
    conf_matrix = pd.crosstab(y_actu, y_pred)

    print(conf_matrix)
    accuracy = np.diag(conf_matrix).sum() / conf_matrix.to_numpy().sum()
    print("######################")
    print(result_title + " Accuracy: " + str(round(eval_result[1],4)*100) + "%")
    print("######################")


Model Development - The Iterative Cycle

This will be the longest section of the article as we attempt to explain the thought process behind each tried and tested model. For each model, we will try to be as descriptive as possible and the corresponding results of each model, will also be shown in this section itself (rather than using a different section for Results).

In this section, you will be guided through the process followed by us in implementing and improving the models in an iterative manner. Since this is an iterative procedure, the model accuracy was considered as the single number evaluation metric, and the improvements/modifications are made to models based on the result of the model accuracy obtained by evaluating the validation dataset.

Model 001

The initial model was created to represent the most basic neural network with Input > Dense where we used Adam as the optimizer.

def convolutional_model(input_shape):
    input_img = tf.keras.Input(shape=input_shape)
    F = tf.keras.layers.Flatten()(input_img)
    outputs = tf.keras.layers.Dense(units = 43, activation = 'softmax')(F)
    model = tf.keras.Model(inputs=input_img, outputs=outputs)
    return model

conv_model_v1 = convolutional_model((30, 30, 3))
conv_model_v1.compile(optimizer='adam',
                  loss='categorical_crossentropy',
                  metrics=['accuracy'])
conv_model_v1.summary()
train_and_plot(conv_model_v1)
evaluate_validation(model = conv_model_v1, no_of_images = 32, rows = 7, columns = 7, type = 'val')

Upon training and plotting, the following outcome was obtained. As it turned out, a validation accuracy of 90.16% was achieved. For a basic neural network, this was an excellent result.

Training and Plotting Results - Model 001

Epoch 1/10
491/491 [==============================] - 2s 4ms/step - loss: 2.0973 - accuracy: 0.5373 - val_loss: 1.4628 - val_accuracy: 0.7042
Epoch 2/10
491/491 [==============================] - 2s 3ms/step - loss: 1.2372 - accuracy: 0.7553 - val_loss: 1.0785 - val_accuracy: 0.7844
Epoch 3/10
491/491 [==============================] - 2s 3ms/step - loss: 0.9560 - accuracy: 0.8221 - val_loss: 0.8889 - val_accuracy: 0.8213
Epoch 4/10
491/491 [==============================] - 2s 3ms/step - loss: 0.7964 - accuracy: 0.8552 - val_loss: 0.7673 - val_accuracy: 0.8475
Epoch 5/10
491/491 [==============================] - 2s 3ms/step - loss: 0.6903 - accuracy: 0.8755 - val_loss: 0.6821 - val_accuracy: 0.8671
Epoch 6/10
491/491 [==============================] - 2s 3ms/step - loss: 0.6133 - accuracy: 0.8893 - val_loss: 0.6203 - val_accuracy: 0.8795
Epoch 7/10
491/491 [==============================] - 2s 3ms/step - loss: 0.5540 - accuracy: 0.8992 - val_loss: 0.5724 - val_accuracy: 0.8898
Epoch 8/10
491/491 [==============================] - 2s 3ms/step - loss: 0.5067 - accuracy: 0.9078 - val_loss: 0.5360 - val_accuracy: 0.8949
Epoch 9/10
491/491 [==============================] - 2s 3ms/step - loss: 0.4680 - accuracy: 0.9141 - val_loss: 0.5084 - val_accuracy: 0.8999
Epoch 10/10
491/491 [==============================] - 2s 3ms/step - loss: 0.4354 - accuracy: 0.9195 - val_loss: 0.4859 - val_accuracy: 0.9016

246/246 [==============================] - 0s 2ms/step - loss: 0.4859 - accuracy: 0.9016
######################
VALIDATION Accuracy: 90.16%
######################

Model 002

In this model, the Model 001 is improved by adding a convolutional layer.

def convolutional_model(input_shape):
    input_img = tf.keras.Input(shape=input_shape)
    Z1 = tf.keras.layers.Conv2D(filters=32, kernel_size= (5, 5), activation = 'relu')(input_img)
    F = tf.keras.layers.Flatten()(Z1)
    outputs = tf.keras.layers.Dense(units = 43, activation = 'softmax')(F)
    model = tf.keras.Model(inputs=input_img, outputs=outputs)
    return model

conv_model_v2 = convolutional_model((30, 30, 3))
conv_model_v2.compile(optimizer='adam',
                  loss='categorical_crossentropy',
                  metrics=['accuracy'])
conv_model_v2.summary()
train_and_plot(conv_model_v2, epochs = 10)
evaluate_validation(model = conv_model_v2, no_of_images = 49, rows = 7, columns = 7, type = 'val')

After training, the validation accuracy was increased by the model up to 97.13%. Can we improve it further?

Validation Accuracy of Model 001 = 90.16%
Validation Accuracy of Model 002 = 97.13%

Training and Plotting Results - Model 002

Epoch 1/10
491/491 [==============================] - 14s 29ms/step - loss: 0.8728 - accuracy: 0.7880 - val_loss: 0.3256 - val_accuracy: 0.9299
Epoch 2/10
491/491 [==============================] - 14s 29ms/step - loss: 0.2117 - accuracy: 0.9495 - val_loss: 0.2012 - val_accuracy: 0.9569
Epoch 3/10
491/491 [==============================] - 14s 28ms/step - loss: 0.1183 - accuracy: 0.9723 - val_loss: 0.1655 - val_accuracy: 0.9647
Epoch 4/10
491/491 [==============================] - 14s 29ms/step - loss: 0.0850 - accuracy: 0.9796 - val_loss: 0.1794 - val_accuracy: 0.9588
Epoch 5/10
491/491 [==============================] - 14s 29ms/step - loss: 0.0725 - accuracy: 0.9821 - val_loss: 0.1592 - val_accuracy: 0.9663
Epoch 6/10
491/491 [==============================] - 14s 29ms/step - loss: 0.0491 - accuracy: 0.9869 - val_loss: 0.1543 - val_accuracy: 0.9644
Epoch 7/10
491/491 [==============================] - 15s 30ms/step - loss: 0.0519 - accuracy: 0.9866 - val_loss: 0.1247 - val_accuracy: 0.9748
Epoch 8/10
491/491 [==============================] - 14s 29ms/step - loss: 0.0389 - accuracy: 0.9898 - val_loss: 0.1205 - val_accuracy: 0.9773
Epoch 9/10
491/491 [==============================] - 14s 29ms/step - loss: 0.0301 - accuracy: 0.9928 - val_loss: 0.1227 - val_accuracy: 0.9773
Epoch 10/10
491/491 [==============================] - 15s 30ms/step - loss: 0.0271 - accuracy: 0.9930 - val_loss: 0.1390 - val_accuracy: 0.9713
246/246 [==============================] - 1s 6ms/step - loss: 0.1390 - accuracy: 0.9713

Model 003

This is an attempted improvement from Model 002 by adding a MaxPool2D layer.

def convolutional_model(input_shape):
    input_img = tf.keras.Input(shape=input_shape)
    Z1 = tf.keras.layers.Conv2D(filters=32, kernel_size= (5, 5), activation = 'relu')(input_img)
    P1 = tf.keras.layers.MaxPool2D(pool_size=(2, 2))(Z1)
    F = tf.keras.layers.Flatten()(P1)
    outputs = tf.keras.layers.Dense(units = 43, activation = 'softmax')(F)
    model = tf.keras.Model(inputs=input_img, outputs=outputs)
    return model

conv_model_v3 = convolutional_model((30, 30, 3))
conv_model_v3.compile(optimizer='adam',
                  loss='categorical_crossentropy',
                  metrics=['accuracy'])
conv_model_v3.summary()
train_and_plot(conv_model_v3, epochs = 10)
evaluate_validation(model = conv_model_v3, no_of_images = 49, rows = 7, columns = 7, type = 'val')

The results between Model 002 and Model 003 are similar. However, there's a noticeable difference between the Training Error and Validation Error and this is an indication of overfitting.

Validation Accuracy of Model 002 = 97.13%
Validation Accuracy of Model 003 = 97.45%

Training and Plotting Results - Model 003

Epoch 1/10
491/491 [==============================] - 15s 30ms/step - loss: 1.0802 - accuracy: 0.7429 - val_loss: 0.3993 - val_accuracy: 0.9161
Epoch 2/10
491/491 [==============================] - 15s 30ms/step - loss: 0.2667 - accuracy: 0.9440 - val_loss: 0.2223 - val_accuracy: 0.9510
Epoch 3/10
491/491 [==============================] - 15s 31ms/step - loss: 0.1482 - accuracy: 0.9693 - val_loss: 0.1708 - val_accuracy: 0.9610
Epoch 4/10
491/491 [==============================] - 15s 30ms/step - loss: 0.0971 - accuracy: 0.9806 - val_loss: 0.1510 - val_accuracy: 0.9648
Epoch 5/10
491/491 [==============================] - 16s 32ms/step - loss: 0.0702 - accuracy: 0.9862 - val_loss: 0.1266 - val_accuracy: 0.9727
Epoch 6/10
491/491 [==============================] - 15s 32ms/step - loss: 0.0546 - accuracy: 0.9887 - val_loss: 0.1272 - val_accuracy: 0.9709
Epoch 7/10
491/491 [==============================] - 16s 33ms/step - loss: 0.0561 - accuracy: 0.9885 - val_loss: 0.1198 - val_accuracy: 0.9754
Epoch 8/10
491/491 [==============================] - 15s 31ms/step - loss: 0.0422 - accuracy: 0.9911 - val_loss: 0.1137 - val_accuracy: 0.9770
Epoch 9/10
491/491 [==============================] - 15s 31ms/step - loss: 0.0338 - accuracy: 0.9925 - val_loss: 0.1097 - val_accuracy: 0.9762
Epoch 10/10
491/491 [==============================] - 16s 32ms/step - loss: 0.0277 - accuracy: 0.9942 - val_loss: 0.1169 - val_accuracy: 0.9745
246/246 [==============================] - 1s 6ms/step - loss: 0.1169 - accuracy: 0.9745

Model 004

We will add another Convolutional Layer too see if the results improve to minimize the bias (before focusing on the overfitting problems).

def convolutional_model(input_shape):
    input_img = tf.keras.Input(shape=input_shape)
    Z1 = tf.keras.layers.Conv2D(filters=32, kernel_size= (5, 5), activation = 'relu')(input_img)
    P1 = tf.keras.layers.MaxPool2D(pool_size=(2, 2))(Z1)
    Z2 = tf.keras.layers.Conv2D(filters=64, kernel_size= (5, 5), activation = 'relu')(P1)
    F = tf.keras.layers.Flatten()(Z2)
    outputs = tf.keras.layers.Dense(units = 43, activation = 'softmax')(F)
    model = tf.keras.Model(inputs=input_img, outputs=outputs)
    return model

conv_model_v4 = convolutional_model((30, 30, 3))
conv_model_v4.compile(optimizer='adam',
                  loss='categorical_crossentropy',
                  metrics=['accuracy'])
conv_model_v4.summary()
train_and_plot(conv_model_v4, epochs = 10)
evaluate_validation(model = conv_model_4, no_of_images = 49, rows = 7, columns = 7, type = 'val')

While the validation accuracy improved by approximately 1%, the overfitting problem remains an issue due to the difference between the Training Error and Validation Error.

Validation Accuracy of Model 003 = 97.45%
Validation Accuracy of Model 004 = 98.51%

Training and Plotting Results - Model 004

Epoch 1/10
491/491 [==============================] - 26s 53ms/step - loss: 0.8186 - accuracy: 0.7919 - val_loss: 0.2310 - val_accuracy: 0.9498
Epoch 2/10
491/491 [==============================] - 27s 55ms/step - loss: 0.1544 - accuracy: 0.9647 - val_loss: 0.1435 - val_accuracy: 0.9675
Epoch 3/10
491/491 [==============================] - 30s 60ms/step - loss: 0.0759 - accuracy: 0.9824 - val_loss: 0.0957 - val_accuracy: 0.9800
Epoch 4/10
491/491 [==============================] - 29s 59ms/step - loss: 0.0426 - accuracy: 0.9901 - val_loss: 0.0951 - val_accuracy: 0.9796
Epoch 5/10
491/491 [==============================] - 28s 58ms/step - loss: 0.0297 - accuracy: 0.9926 - val_loss: 0.0839 - val_accuracy: 0.9837
Epoch 6/10
491/491 [==============================] - 28s 56ms/step - loss: 0.0223 - accuracy: 0.9942 - val_loss: 0.0870 - val_accuracy: 0.9813
Epoch 7/10
491/491 [==============================] - 27s 55ms/step - loss: 0.0221 - accuracy: 0.9947 - val_loss: 0.0908 - val_accuracy: 0.9816
Epoch 8/10
491/491 [==============================] - 27s 56ms/step - loss: 0.0247 - accuracy: 0.9931 - val_loss: 0.0877 - val_accuracy: 0.9836
Epoch 9/10
491/491 [==============================] - 27s 56ms/step - loss: 0.0110 - accuracy: 0.9973 - val_loss: 0.1071 - val_accuracy: 0.9821
Epoch 10/10
491/491 [==============================] - 28s 57ms/step - loss: 0.0069 - accuracy: 0.9984 - val_loss: 0.0817 - val_accuracy: 0.9851
246/246 [==============================] - 2s 8ms/step - loss: 0.0817 - accuracy: 0.9851

Model 005

We will add another MaxPooling2D Layer before going ahead with the regularization to tackle the overfitting problem.

def convolutional_model(input_shape):
    input_img = tf.keras.Input(shape=input_shape)
    Z1 = tf.keras.layers.Conv2D(filters=32, kernel_size= (5, 5), activation = 'relu')(input_img)
    P1 = tf.keras.layers.MaxPool2D(pool_size=(2, 2))(Z1)
    Z2 = tf.keras.layers.Conv2D(filters=64, kernel_size= (5, 5), activation = 'relu')(P1)
    P2 = tf.keras.layers.MaxPool2D(pool_size=(2, 2))(Z2)
    F = tf.keras.layers.Flatten()(P2)
    outputs = tf.keras.layers.Dense(units = 43, activation = 'softmax')(F)
    model = tf.keras.Model(inputs=input_img, outputs=outputs)
    return model

conv_model_v5 = convolutional_model((30, 30, 3))
conv_model_v5.compile(optimizer='adam',
                  loss='categorical_crossentropy',
                  metrics=['accuracy'])
conv_model_v5.summary()
train_and_plot(conv_model_v8, epochs = 10)

There is a slight improvement in the validation accuracy from 98.51% to 98.83%. However, there is still a slight difference between the training and validation accuracies.

Validation Accuracy of Model 004 = 98.51%
Validation Accuracy of Model 005 = 98.83%

Training and Plotting Results - Model 005

Epoch 1/10
491/491 [==============================] - 25s 51ms/step - loss: 1.1546 - accuracy: 0.7134 - val_loss: 0.3212 - val_accuracy: 0.9245
Epoch 2/10
491/491 [==============================] - 25s 50ms/step - loss: 0.2106 - accuracy: 0.9515 - val_loss: 0.1631 - val_accuracy: 0.9611
Epoch 3/10
491/491 [==============================] - 26s 53ms/step - loss: 0.1069 - accuracy: 0.9764 - val_loss: 0.1229 - val_accuracy: 0.9697
Epoch 4/10
491/491 [==============================] - 26s 54ms/step - loss: 0.0641 - accuracy: 0.9858 - val_loss: 0.1016 - val_accuracy: 0.9749
Epoch 5/10
491/491 [==============================] - 27s 54ms/step - loss: 0.0441 - accuracy: 0.9908 - val_loss: 0.0819 - val_accuracy: 0.9815
Epoch 6/10
491/491 [==============================] - 26s 54ms/step - loss: 0.0311 - accuracy: 0.9936 - val_loss: 0.0754 - val_accuracy: 0.9829
Epoch 7/10
491/491 [==============================] - 27s 55ms/step - loss: 0.0274 - accuracy: 0.9935 - val_loss: 0.1225 - val_accuracy: 0.9750
Epoch 8/10
491/491 [==============================] - 26s 53ms/step - loss: 0.0188 - accuracy: 0.9956 - val_loss: 0.0646 - val_accuracy: 0.9846
Epoch 9/10
491/491 [==============================] - 25s 51ms/step - loss: 0.0211 - accuracy: 0.9951 - val_loss: 0.0637 - val_accuracy: 0.9866
Epoch 10/10
491/491 [==============================] - 25s 51ms/step - loss: 0.0170 - accuracy: 0.9960 - val_loss: 0.0621 - val_accuracy: 0.9883
246/246 [==============================] - 2s 8ms/step - loss: 0.0621 - accuracy: 0.9883

Model 006

Because of the difference between the training and validation accuracies, we are now adding a Dropout layer to address the overfitting problem.

def convolutional_model(input_shape):
    input_img = tf.keras.Input(shape=input_shape)
    Z1 = tf.keras.layers.Conv2D(filters=32, kernel_size= (5, 5), activation = 'relu')(input_img)
    P1 = tf.keras.layers.MaxPool2D(pool_size=(2, 2))(Z1)
    D1 = tf.keras.layers.Dropout(rate = 0.25)(P1)
    Z2 = tf.keras.layers.Conv2D(filters=64, kernel_size= (5, 5), activation = 'relu')(D1)
    P2 = tf.keras.layers.MaxPool2D(pool_size=(2, 2))(Z2)
    F = tf.keras.layers.Flatten()(P2)
    outputs = tf.keras.layers.Dense(units = 43, activation = 'softmax')(F)
    model = tf.keras.Model(inputs=input_img, outputs=outputs)
    return model

conv_model_v6 = convolutional_model((30, 30, 3))
conv_model_v6.compile(optimizer='adam',
                  loss='categorical_crossentropy',
                  metrics=['accuracy'])
conv_model_v6.summary()
train_and_plot(conv_model_v6, epochs = 10)
evaluate_validation(model = conv_model_v6, no_of_images = 49, rows = 7, columns = 7, type = 'val')

The Dropout certainly had an effect in narrowing down the gap between Training Error and Validation Error. However, there is an indication of validation accuracy going down after Epoch 09. In such cases, Early Stopping may come in handy.

Validation Accuracy of Model 005 = 98.83%
Validation Accuracy of Model 006 = 98.83%

Training and Plotting Results - Model 006

Epoch 1/10
491/491 [==============================] - 29s 59ms/step - loss: 1.2292 - accuracy: 0.6867 - val_loss: 0.3695 - val_accuracy: 0.9115
Epoch 2/10
491/491 [==============================] - 29s 59ms/step - loss: 0.2606 - accuracy: 0.9351 - val_loss: 0.1708 - val_accuracy: 0.9634
Epoch 3/10
491/491 [==============================] - 30s 62ms/step - loss: 0.1393 - accuracy: 0.9661 - val_loss: 0.1292 - val_accuracy: 0.9686
Epoch 4/10
491/491 [==============================] - 30s 61ms/step - loss: 0.0874 - accuracy: 0.9791 - val_loss: 0.0912 - val_accuracy: 0.9802
Epoch 5/10
491/491 [==============================] - 29s 59ms/step - loss: 0.0680 - accuracy: 0.9835 - val_loss: 0.0797 - val_accuracy: 0.9815
Epoch 6/10
491/491 [==============================] - 29s 59ms/step - loss: 0.0496 - accuracy: 0.9882 - val_loss: 0.0736 - val_accuracy: 0.9847
Epoch 7/10
491/491 [==============================] - 30s 60ms/step - loss: 0.0411 - accuracy: 0.9896 - val_loss: 0.0669 - val_accuracy: 0.9846
Epoch 8/10
491/491 [==============================] - 29s 60ms/step - loss: 0.0362 - accuracy: 0.9899 - val_loss: 0.0481 - val_accuracy: 0.9894
Epoch 9/10
491/491 [==============================] - 30s 60ms/step - loss: 0.0285 - accuracy: 0.9928 - val_loss: 0.0496 - val_accuracy: 0.9888
Epoch 10/10
491/491 [==============================] - 30s 61ms/step - loss: 0.0259 - accuracy: 0.9936 - val_loss: 0.0557 - val_accuracy: 0.9883
246/246 [==============================] - 2s 8ms/step - loss: 0.0557 - accuracy: 0.9883

Model 007

We will add another Dropout layer to see if we can further fine-tune the model and then let's proceed with Early Stopping if necessary.

# Model 007

def convolutional_model(input_shape):
    input_img = tf.keras.Input(shape=input_shape)
    Z1 = tf.keras.layers.Conv2D(filters=32, kernel_size= (5, 5), activation = 'relu')(input_img)
    P1 = tf.keras.layers.MaxPool2D(pool_size=(2, 2))(Z1)
    D1 = tf.keras.layers.Dropout(rate = 0.25)(P1)
    Z2 = tf.keras.layers.Conv2D(filters=64, kernel_size= (5, 5), activation = 'relu')(D1)
    P2 = tf.keras.layers.MaxPool2D(pool_size=(2, 2))(Z2)
    D2 = tf.keras.layers.Dropout(rate = 0.25)(P2)
    F = tf.keras.layers.Flatten()(D2)
    outputs = tf.keras.layers.Dense(units = 43, activation = 'softmax')(F)
    model = tf.keras.Model(inputs=input_img, outputs=outputs)
    return model

conv_model_v7 = convolutional_model((30, 30, 3))
conv_model_v7.compile(optimizer='adam',
                  loss='categorical_crossentropy',
                  metrics=['accuracy'])
conv_model_v7.summary()
train_and_plot(conv_model_v7, epochs = 10)
evaluate_validation(model = conv_model_v7, no_of_images = 49, rows = 7, columns = 7, type = 'val')

The validation accuracy slightly improved from 98.83% to 99.22%.

Validation Accuracy of Model 006 = 98.83%
Validation Accuracy of Model 007 = 99.22%

Training and Plotting Results - Model 007

Epoch 1/10
491/491 [==============================] - 30s 61ms/step - loss: 1.3423 - accuracy: 0.6474 - val_loss: 0.3653 - val_accuracy: 0.9217
Epoch 2/10
491/491 [==============================] - 30s 62ms/step - loss: 0.3166 - accuracy: 0.9155 - val_loss: 0.1653 - val_accuracy: 0.9675
Epoch 3/10
491/491 [==============================] - 31s 64ms/step - loss: 0.1760 - accuracy: 0.9539 - val_loss: 0.1124 - val_accuracy: 0.9784
Epoch 4/10
491/491 [==============================] - 36s 74ms/step - loss: 0.1198 - accuracy: 0.9687 - val_loss: 0.0857 - val_accuracy: 0.9844
Epoch 5/10
491/491 [==============================] - 39s 80ms/step - loss: 0.0861 - accuracy: 0.9769 - val_loss: 0.0709 - val_accuracy: 0.9837
Epoch 6/10
491/491 [==============================] - 32s 66ms/step - loss: 0.0710 - accuracy: 0.9808 - val_loss: 0.0517 - val_accuracy: 0.9892
Epoch 7/10
491/491 [==============================] - 41s 84ms/step - loss: 0.0621 - accuracy: 0.9830 - val_loss: 0.0535 - val_accuracy: 0.9895
Epoch 8/10
491/491 [==============================] - 34s 68ms/step - loss: 0.0486 - accuracy: 0.9868 - val_loss: 0.0422 - val_accuracy: 0.9922
Epoch 9/10
491/491 [==============================] - 30s 61ms/step - loss: 0.0424 - accuracy: 0.9881 - val_loss: 0.0458 - val_accuracy: 0.9903
Epoch 10/10
491/491 [==============================] - 30s 62ms/step - loss: 0.0416 - accuracy: 0.9881 - val_loss: 0.0387 - val_accuracy: 0.9922
246/246 [==============================] - 2s 8ms/step - loss: 0.0387 - accuracy: 0.9922

Model 008

Adding more layers make the network deeper and having a bigger network almost always helps in minimizing the bias, and for increasing the accuracy. Therefore, we will add another Convolutional Layer to see if we can further increase the Validation Accuracy. On the other hand, the validation accuracy surpassed the training accuracy, and this happens due to the effect of Dropout.

def convolutional_model(input_shape):
    input_img = tf.keras.Input(shape=input_shape)
    Z1 = tf.keras.layers.Conv2D(filters=32, kernel_size= (5, 5), activation = 'relu')(input_img)
    P1 = tf.keras.layers.MaxPool2D(pool_size=(2, 2))(Z1)
    D1 = tf.keras.layers.Dropout(rate = 0.25)(P1)
    Z2 = tf.keras.layers.Conv2D(filters=64, kernel_size= (5, 5), activation = 'relu')(D1)
    P2 = tf.keras.layers.MaxPool2D(pool_size=(2, 2))(Z2)
    D2 = tf.keras.layers.Dropout(rate = 0.25)(P2)
    Z3 = tf.keras.layers.Conv2D(filters=256, kernel_size= (3, 3), activation = 'relu')(D2)
    F = tf.keras.layers.Flatten()(Z3)
    outputs = tf.keras.layers.Dense(units = 43, activation = 'softmax')(F)
    model = tf.keras.Model(inputs=input_img, outputs=outputs)
    return model

conv_model_v8 = convolutional_model((30, 30, 3))
conv_model_v8.compile(optimizer='adam',
                  loss='categorical_crossentropy',
                  metrics=['accuracy'])
conv_model_v8.summary()
train_and_plot(conv_model_v8, epochs = 10)
evaluate_validation(model = conv_model_v8, no_of_images = 49, rows = 7, columns = 7, type = 'val')

The validation accuracy slightly improved from 99.22% to 99.34%.

Validation Accuracy of Model 007 = 98.22%
Validation Accuracy of Model 008 = 99.34%


Training and Plotting Results - Model 008
Epoch 1/10
491/491 [==============================] - 31s 63ms/step - loss: 1.1019 - accuracy: 0.6988 - val_loss: 0.2339 - val_accuracy: 0.9439
Epoch 2/10
491/491 [==============================] - 32s 65ms/step - loss: 0.2157 - accuracy: 0.9404 - val_loss: 0.1071 - val_accuracy: 0.9740
Epoch 3/10
491/491 [==============================] - 35s 72ms/step - loss: 0.1245 - accuracy: 0.9656 - val_loss: 0.0783 - val_accuracy: 0.9830
Epoch 4/10
491/491 [==============================] - 33s 67ms/step - loss: 0.0837 - accuracy: 0.9761 - val_loss: 0.0574 - val_accuracy: 0.9892
Epoch 5/10
491/491 [==============================] - 34s 70ms/step - loss: 0.0669 - accuracy: 0.9806 - val_loss: 0.0595 - val_accuracy: 0.9884
Epoch 6/10
491/491 [==============================] - 33s 68ms/step - loss: 0.0540 - accuracy: 0.9848 - val_loss: 0.0446 - val_accuracy: 0.9926
Epoch 7/10
491/491 [==============================] - 35s 71ms/step - loss: 0.0424 - accuracy: 0.9877 - val_loss: 0.0486 - val_accuracy: 0.9899
Epoch 8/10
491/491 [==============================] - 33s 68ms/step - loss: 0.0447 - accuracy: 0.9868 - val_loss: 0.0429 - val_accuracy: 0.9911
Epoch 9/10
491/491 [==============================] - 36s 73ms/step - loss: 0.0405 - accuracy: 0.9879 - val_loss: 0.0373 - val_accuracy: 0.9930
Epoch 10/10
491/491 [==============================] - 38s 78ms/step - loss: 0.0393 - accuracy: 0.9881 - val_loss: 0.0392 - val_accuracy: 0.9934
246/246 [==============================] - 2s 10ms/step - loss: 0.0392 - accuracy: 0.9934

Model 009

We further add another MaxPool2D layer, followed by a Dropout layer.

def convolutional_model(input_shape):
    input_img = tf.keras.Input(shape=input_shape)
    Z1 = tf.keras.layers.Conv2D(filters=32, kernel_size= (5, 5), activation = 'relu')(input_img)
    P1 = tf.keras.layers.MaxPool2D(pool_size=(2, 2))(Z1)
    D1 = tf.keras.layers.Dropout(rate = 0.25)(P1)
    Z2 = tf.keras.layers.Conv2D(filters=64, kernel_size= (5, 5), activation = 'relu')(D1)
    P2 = tf.keras.layers.MaxPool2D(pool_size=(2, 2))(Z2)
    D2 = tf.keras.layers.Dropout(rate = 0.25)(P2)
    Z3 = tf.keras.layers.Conv2D(filters=256, kernel_size= (3, 3), activation = 'relu')(D2)
    P3 = tf.keras.layers.MaxPool2D(pool_size=(2, 2))(Z3)
    D3 = tf.keras.layers.Dropout(rate = 0.25)(P3)
    F = tf.keras.layers.Flatten()(D3)
    outputs = tf.keras.layers.Dense(units = 43, activation = 'softmax')(F)
    model = tf.keras.Model(inputs=input_img, outputs=outputs)
    return model

conv_model_v9 = convolutional_model((30, 30, 3))
conv_model_v9.compile(optimizer='adam',
                  loss='categorical_crossentropy',
                  metrics=['accuracy'])
conv_model_v9.summary()
train_and_plot(conv_model_v9, epochs = 10)
evaluate_validation(model = conv_model_v9, no_of_images = 49, rows = 7, columns = 7, type = 'val')

The validation accuracy slightly improved from 99.34% to 99.36%.

Validation Accuracy of Model 008 = 98.34%
Validation Accuracy of Model 009 = 99.36%Training and Plotting Result - Model 009

Training and Plotting Results - Model 009

Epoch 1/10
491/491 [==============================] - 32s 64ms/step - loss: 1.8729 - accuracy: 0.4747 - val_loss: 0.4384 - val_accuracy: 0.8979
Epoch 2/10
491/491 [==============================] - 33s 66ms/step - loss: 0.4269 - accuracy: 0.8749 - val_loss: 0.1343 - val_accuracy: 0.9718
Epoch 3/10
491/491 [==============================] - 34s 69ms/step - loss: 0.2201 - accuracy: 0.9376 - val_loss: 0.0722 - val_accuracy: 0.9852
Epoch 4/10
491/491 [==============================] - 34s 69ms/step - loss: 0.1456 - accuracy: 0.9567 - val_loss: 0.0498 - val_accuracy: 0.9895
Epoch 5/10
491/491 [==============================] - 34s 69ms/step - loss: 0.1102 - accuracy: 0.9676 - val_loss: 0.0382 - val_accuracy: 0.9926
Epoch 6/10
491/491 [==============================] - 34s 70ms/step - loss: 0.0923 - accuracy: 0.9729 - val_loss: 0.0380 - val_accuracy: 0.9932
Epoch 7/10
491/491 [==============================] - 34s 69ms/step - loss: 0.0773 - accuracy: 0.9774 - val_loss: 0.0426 - val_accuracy: 0.9902
Epoch 8/10
491/491 [==============================] - 33s 67ms/step - loss: 0.0692 - accuracy: 0.9800 - val_loss: 0.0265 - val_accuracy: 0.9943
Epoch 9/10
491/491 [==============================] - 32s 66ms/step - loss: 0.0570 - accuracy: 0.9839 - val_loss: 0.0249 - val_accuracy: 0.9939
Epoch 10/10
491/491 [==============================] - 32s 65ms/step - loss: 0.0630 - accuracy: 0.9807 - val_loss: 0.0290 - val_accuracy: 0.9936

Model 010

Now, we will add a Fully Connected Layer to see if it improves the overall performance (and minimize the bias).

def convolutional_model(input_shape):
    input_img = tf.keras.Input(shape=input_shape)
    Z1 = tf.keras.layers.Conv2D(filters=32, kernel_size= (5, 5), activation = 'relu')(input_img)
    P1 = tf.keras.layers.MaxPool2D(pool_size=(2, 2))(Z1)
    D1 = tf.keras.layers.Dropout(rate = 0.25)(P1)
    Z2 = tf.keras.layers.Conv2D(filters=64, kernel_size= (5, 5), activation = 'relu')(D1)
    P2 = tf.keras.layers.MaxPool2D(pool_size=(2, 2))(Z2)
    D2 = tf.keras.layers.Dropout(rate = 0.25)(P2)
    Z3 = tf.keras.layers.Conv2D(filters=256, kernel_size= (3, 3), activation = 'relu')(D2)
    P3 = tf.keras.layers.MaxPool2D(pool_size=(2, 2))(Z3)
    D3 = tf.keras.layers.Dropout(rate = 0.25)(P3)
    F = tf.keras.layers.Flatten()(D3)
    FC1 = tf.keras.layers.Dense(units = 256, activation = 'relu')(F)
    outputs = tf.keras.layers.Dense(units = 43, activation = 'softmax')(FC1)
    model = tf.keras.Model(inputs=input_img, outputs=outputs)
    return model

conv_model_v10 = convolutional_model((30, 30, 3))
conv_model_v10.compile(optimizer='adam',
                  loss='categorical_crossentropy',
                  metrics=['accuracy'])
conv_model_v10.summary()
train_and_plot(conv_model_v10, epochs = 10)

Validation Accuracy of Model 009 = 98.36%
Validation Accuracy of Model 010 = 99.38%

Training and Plotting Results - Model 010

Epoch 1/10
491/491 [==============================] - 31s 63ms/step - loss: 2.0385 - accuracy: 0.4115 - val_loss: 0.4938 - val_accuracy: 0.8601
Epoch 2/10
491/491 [==============================] - 31s 63ms/step - loss: 0.4200 - accuracy: 0.8677 - val_loss: 0.1395 - val_accuracy: 0.9675
Epoch 3/10
491/491 [==============================] - 32s 66ms/step - loss: 0.2112 - accuracy: 0.9377 - val_loss: 0.0846 - val_accuracy: 0.9793
Epoch 4/10
491/491 [==============================] - 32s 65ms/step - loss: 0.1538 - accuracy: 0.9545 - val_loss: 0.0630 - val_accuracy: 0.9856
Epoch 5/10
491/491 [==============================] - 32s 65ms/step - loss: 0.1147 - accuracy: 0.9645 - val_loss: 0.0494 - val_accuracy: 0.9878
Epoch 6/10
491/491 [==============================] - 32s 65ms/step - loss: 0.0984 - accuracy: 0.9698 - val_loss: 0.0545 - val_accuracy: 0.9858
Epoch 7/10
491/491 [==============================] - 32s 66ms/step - loss: 0.0881 - accuracy: 0.9729 - val_loss: 0.0326 - val_accuracy: 0.9918
Epoch 8/10
491/491 [==============================] - 32s 65ms/step - loss: 0.0778 - accuracy: 0.9764 - val_loss: 0.0275 - val_accuracy: 0.9935
Epoch 9/10
491/491 [==============================] - 32s 65ms/step - loss: 0.0679 - accuracy: 0.9787 - val_loss: 0.0291 - val_accuracy: 0.9920
Epoch 10/10
491/491 [==============================] - 32s 66ms/step - loss: 0.0736 - accuracy: 0.9782 - val_loss: 0.0226 - val_accuracy: 0.9938
246/246 [==============================] - 2s 9ms/step - loss: 0.0226 - accuracy: 0.9938

Model 011

While it may not have a considerable effect, it is worth a try to add a regularizer to the Fully Connected Layer.

def convolutional_model(input_shape):
    input_img = tf.keras.Input(shape=input_shape)
    Z1 = tf.keras.layers.Conv2D(filters=32, kernel_size= (5, 5), activation = 'relu')(input_img)
    P1 = tf.keras.layers.MaxPool2D(pool_size=(2, 2))(Z1)
    D1 = tf.keras.layers.Dropout(rate = 0.25)(P1)
    Z2 = tf.keras.layers.Conv2D(filters=64, kernel_size= (5, 5), activation = 'relu')(D1)
    P2 = tf.keras.layers.MaxPool2D(pool_size=(2, 2))(Z2)
    D2 = tf.keras.layers.Dropout(rate = 0.25)(P2)
    Z3 = tf.keras.layers.Conv2D(filters=256, kernel_size= (3, 3), activation = 'relu')(D2)
    P3 = tf.keras.layers.MaxPool2D(pool_size=(2, 2))(Z3)
    D3 = tf.keras.layers.Dropout(rate = 0.25)(P3)
    F = tf.keras.layers.Flatten()(D3)
    FC1 = tf.keras.layers.Dense(units = 256, activation = 'relu', kernel_regularizer=regularizers.l2(0.0001))(F)
    outputs = tf.keras.layers.Dense(units = 43, activation = 'softmax')(FC1)
    model = tf.keras.Model(inputs=input_img, outputs=outputs)
    return model

conv_model_v11 = convolutional_model((30, 30, 3))
conv_model_v11.compile(optimizer='adam',
                  loss='categorical_crossentropy',
                  metrics=['accuracy'])
conv_model_v11.summary()
train_and_plot(conv_model_v11, epochs = 10)
evaluate_validation(model = conv_model_v11, no_of_images = 49, rows = 7, columns = 7, type = 'val')

Validation Accuracy of Model 010 = 99.38%
Validation Accuracy of Model 011 = 99.44%

Epoch 1/10
491/491 [==============================] - 32s 66ms/step - loss: 1.9605 - accuracy: 0.4357 - val_loss: 0.5152 - val_accuracy: 0.8624
Epoch 2/10
491/491 [==============================] - 34s 69ms/step - loss: 0.4549 - accuracy: 0.8630 - val_loss: 0.1577 - val_accuracy: 0.9679
Epoch 3/10
491/491 [==============================] - 33s 67ms/step - loss: 0.2494 - accuracy: 0.9301 - val_loss: 0.1195 - val_accuracy: 0.9779
Epoch 4/10
491/491 [==============================] - 32s 66ms/step - loss: 0.1742 - accuracy: 0.9527 - val_loss: 0.0850 - val_accuracy: 0.9860
Epoch 5/10
491/491 [==============================] - 32s 66ms/step - loss: 0.1446 - accuracy: 0.9633 - val_loss: 0.0758 - val_accuracy: 0.9889
Epoch 6/10
491/491 [==============================] - 33s 66ms/step - loss: 0.1236 - accuracy: 0.9696 - val_loss: 0.0676 - val_accuracy: 0.9908
Epoch 7/10
491/491 [==============================] - 33s 67ms/step - loss: 0.1121 - accuracy: 0.9726 - val_loss: 0.0618 - val_accuracy: 0.9918
Epoch 8/10
491/491 [==============================] - 34s 68ms/step - loss: 0.1026 - accuracy: 0.9765 - val_loss: 0.0585 - val_accuracy: 0.9920
Epoch 9/10
491/491 [==============================] - 32s 66ms/step - loss: 0.0965 - accuracy: 0.9778 - val_loss: 0.0539 - val_accuracy: 0.9926
Epoch 10/10
491/491 [==============================] - 33s 66ms/step - loss: 0.0914 - accuracy: 0.9789 - val_loss: 0.0495 - val_accuracy: 0.9944
246/246 [==============================] - 2s 10ms/step - loss: 0.0495 - accuracy: 0.9944

Since we have achieved an acceptable accuracy, let us try to train longer by increasing the number of epochs. While training longer does not always help, it never hurts to try training longer.

train_and_plot(conv_model_v11, epochs = 20)

Validation Accuracy of Model 011 (with 10 epochs) = 99.44%
Validation Accuracy of Model 011 (with 20 epochs) = 99.53%

Epoch 1/20
491/491 [==============================] - 30s 62ms/step - loss: 0.0867 - accuracy: 0.9806 - val_loss: 0.0511 - val_accuracy: 0.9939
Epoch 2/20
491/491 [==============================] - 32s 64ms/step - loss: 0.0804 - accuracy: 0.9834 - val_loss: 0.0518 - val_accuracy: 0.9938
Epoch 3/20
491/491 [==============================] - 34s 69ms/step - loss: 0.0764 - accuracy: 0.9835 - val_loss: 0.0454 - val_accuracy: 0.9948
Epoch 4/20
491/491 [==============================] - 32s 65ms/step - loss: 0.0710 - accuracy: 0.9849 - val_loss: 0.0459 - val_accuracy: 0.9943
Epoch 5/20
491/491 [==============================] - 31s 64ms/step - loss: 0.0719 - accuracy: 0.9844 - val_loss: 0.0494 - val_accuracy: 0.9927
Epoch 6/20
491/491 [==============================] - 31s 64ms/step - loss: 0.0745 - accuracy: 0.9837 - val_loss: 0.0491 - val_accuracy: 0.9941
Epoch 7/20
491/491 [==============================] - 32s 65ms/step - loss: 0.0703 - accuracy: 0.9855 - val_loss: 0.0499 - val_accuracy: 0.9939
Epoch 8/20
491/491 [==============================] - 32s 65ms/step - loss: 0.0694 - accuracy: 0.9853 - val_loss: 0.0545 - val_accuracy: 0.9926
Epoch 9/20
491/491 [==============================] - 33s 67ms/step - loss: 0.0659 - accuracy: 0.9865 - val_loss: 0.0463 - val_accuracy: 0.9952
Epoch 10/20
491/491 [==============================] - 33s 67ms/step - loss: 0.0639 - accuracy: 0.9875 - val_loss: 0.0423 - val_accuracy: 0.9952
Epoch 11/20
491/491 [==============================] - 36s 72ms/step - loss: 0.0603 - accuracy: 0.9873 - val_loss: 0.0386 - val_accuracy: 0.9954
Epoch 12/20
491/491 [==============================] - 32s 66ms/step - loss: 0.0610 - accuracy: 0.9871 - val_loss: 0.0460 - val_accuracy: 0.9935
Epoch 13/20
491/491 [==============================] - 30s 61ms/step - loss: 0.0553 - accuracy: 0.9898 - val_loss: 0.0402 - val_accuracy: 0.9963
Epoch 14/20
491/491 [==============================] - 34s 69ms/step - loss: 0.0625 - accuracy: 0.9869 - val_loss: 0.0393 - val_accuracy: 0.9960
Epoch 15/20
491/491 [==============================] - 40s 81ms/step - loss: 0.0584 - accuracy: 0.9877 - val_loss: 0.0427 - val_accuracy: 0.9957
Epoch 16/20
491/491 [==============================] - 42s 86ms/step - loss: 0.0580 - accuracy: 0.9881 - val_loss: 0.0435 - val_accuracy: 0.9955
Epoch 17/20
491/491 [==============================] - 37s 76ms/step - loss: 0.0532 - accuracy: 0.9900 - val_loss: 0.0431 - val_accuracy: 0.9952
Epoch 18/20
491/491 [==============================] - 35s 71ms/step - loss: 0.0570 - accuracy: 0.9889 - val_loss: 0.0363 - val_accuracy: 0.9959
Epoch 19/20
491/491 [==============================] - 34s 69ms/step - loss: 0.0566 - accuracy: 0.9889 - val_loss: 0.0348 - val_accuracy: 0.9969
Epoch 20/20
491/491 [==============================] - 34s 70ms/step - loss: 0.0517 - accuracy: 0.9896 - val_loss: 0.0423 - val_accuracy: 0.9953
246/246 [==============================] - 2s 8ms/step - loss: 0.0423 - accuracy: 0.9953

We will consider this as the final model because we have been able to achieve a validation accuracy of over 99.50%. The following code snippet should assist us in saving the final model in Hierarchical Data Format version 5 (HDF5).

conv_model_v11.save("gtsrb_v11.h5")

Summary

The table given below, summarizes the results of the models that we implemented.

The Test Drive

ModelAccuracy
Model 00190.16%
Model 00297.13%
Model 00397.45%
Model 00498.51%
Model 00598.83%
Model 00698.83%
Model 00799.22%
Model 00899.34%
Model 00999.36%
Model 01099.38%
Model 01199.53%

This section is used for explaining the results and implications from the Test phase. The emphasis will be placed for detailing out the specific outcomes from both the Test Dataset and the Custom Street View Test Dataset.

In the previous section, we finally chose Model 011 as the final model because of its high validation accuracy. In this section, we will be applying Model 011 on two completely unseen (left out) Test datasets to see its robustness on a production run. Therefore, the model will be applied first to the Test dataset that came from the original dataset.

evaluate_validation(model = conv_model_v11, no_of_images = 49, rows = 7, columns = 7, type = 'test')

395/395 [==============================] - 3s 9ms/step - loss: 0.2013 - accuracy: 0.96371

######################
TEST Accuracy: 96.37%
######################
Sample Images (As predicted by the model on Test dataset)

Voila! The model managed to achieve an accuracy of 96.37% on the completely unseen dataset. Let us see how it performs on the images captured from Google Street View.

evaluate_validation(model = conv_model_v11, no_of_images = 32, rows = 6, columns = 6, type = 'sv')

1/1 [==============================] - 0s 1ms/step - loss: 0.0781 - accuracy: 0.9688

######################
STREETVIEW TEST Accuracy: 96.88%
######################
Sample images (as predicted by the model on Street View dataset)

Again, it showed a similar accuracy for a completely unseen dataset. With a little bit of tweaking and troubleshooting, we should be able to improve the performances. But, let us focus on the enhancements on another day. For the moment, we are happy with the output produced by our model.

Do It Yourself!

Here, we will briefly explain how we build a simple, yet effective web application for testing the algorithm on the go. I think that the development of a web app might be beneficial because it showcases our capability to provide an end-to-end solution since we focus on the deployment process as well.

In the previous sections, we demonstrated how you can build a deep learning models from scratch, and test them against different datasets to measure the respective performances. However, we used the Jupyter Notebook interface to handle our coding experiments. We understand the difficulties posed by such an approach if you are a less tech-savvy person. Thus, we hereby present you a handy web application, where the trained models can be utilized by YOURSELF to experience how the models output results.

The application can be reached by visiting the following link, where the necessary instructions have been given for you to easily classify the traffic signs, YOURSELF! Enjoy!

Traffic Sign Recognizer | Do It Yourself!


Feature Additions

Detection of Unknown Images (From 12-07-2021 to 16-07-2021)

After the development of the web application, we realized that the application does not perform up to the expectations when it is presented with an image which does not consist of a trained traffic sign. Since the model had been instructed to strictly output only the designated traffic signs (43), the model was supposed to say that the submitted image belonged to the category of one of the trained traffic signs. This was a problem that we needed to address, and we followed a methodical approach to minimize the issues arising from our problematic approach.

Novelty/Anomaly detection is a research area, where different approaches have been suggested in the literature by the scholars to tackle the problem which we identified. One of the suggested approaches is to include an additional class to the existing list of classes by retraining the model with random images (non-traffic-sign images). Additionally, it is also suggested to create a binary model as a pre-filter which can classify the images by specifying whether the image is a traffic sign or not. For this approach as well, a set of random images are required for training purposes. If we are to follow a different approach, the option is to train a model using an object detection algorithm such as YOLO, and enhance the usability of the web application.

After considering the advantages and disadvantages of the different approaches mentioned above, it was decided to consider one of the first two approaches, because of the comparatively less effort needed to modify our existing model, while meeting our requirement. However, instead of singling out a particular approach, our intention was to implement a solution utilizing both approaches to increase eventual the user experience. As a result, a pre-filter was developed to create a binary classifier which essentially classifies whether an image is a traffic sign or not. After the binary classification, the images are sent through the usual multi-class classifier where the classifier contains an additional class called “Unknown Traffic Sign” to denote images which do not adhere to the characteristics of a trained traffic sign. The following figure illustrates the proposed combined approach.

Figure: The workflow of web application

In order to implement the workflow given in the above figure, the following changes were applied.

Adding “Unknown Traffic Sign” to the existing model

  • This process increased the number of classes from 43 to 44.
  • To achieve this task, 1930 more random images were added from the COCO Dataset to our training distribution, and assigned the new class label (44: Unknown Traffic Sign) accordingly.
  • At the same time, 615 images from the COCO Dataset, were added to the Test dataset.
  • The same NN architecture that we had used earlier, was utilized with an additional output class, and the model was retrained to achieve a classification accuracy of 99.57% for the validation dataset.
  • The model performed well by minimizing the issues that existed with the recognition of non-traffic-signs.

Development of a binary classifier as a pre-filter

  • This process entails the development of a binary classifier which classifies whether an image is a traffic sign or not.
  • For this purpose, all the images from the GTSRB Traffic Sign dataset (51,839 images) were considered along with 45,670 images from the COCO dataset (non-traffic-signs).
  • Necessary splits and preprocessing tasks were applied before the training process.
  • Improved the model iteratively (as we had done in the previous version) to create the binary classifier.
  • Managed to achieve a validation accuracy of 99.81% and an accuracy of 99.72% for the left-out Test dataset.

Integration

  • As elaborated in the above figure, a submitted image first goes through the binary classifier to detect whether the image is a traffic sign or not. If it is detected as a valid traffic sign, the image will be checked by the traffic sign classifier, and a suitable feedback is sent back to the frontend.
  • If the submitted image is detected as a non-traffic-sign image, the user is prompted with a message, and the user confirmation is required to proceed further (to force the application to classify the image regardless of its type).
  • If the user wishes to proceed, the image is sent

Read More

DevOps Pillars: The Essential Strategies That Strengthen The Development Process

DevOps Pillars: The Essential Strategies That Strengthen The Development Process

DevOps Pillars: The Essential Strategies That Strengthen The Development Process

Software Development (Dev) and information technology operations (Ops) have drawn together DevOps, helping the entire software development process from designs to production support. DevOps methodologies help fasten the development process, QA, and deployment where the companies can launch their products faster to the market.

A shorter development cycle, environment stabilization, reduced defects, and increased release velocity are some of the key benefits of using DevOps. This article briefly discusses the solid pillars of DevOps that help to accelerate businesses and software companies to be efficient and agile, creating applications of DevOps speed and scale.

Leadership and Planning

Leaders can empower organizations with a long-term vision and innovative ideas while stimulating the team with inspirational communication and encouragement. They can also identify the unique skills of individuals and assign tasks accordingly. Therefore, it is essential to have a great lead in bringing the best out of the developer team.

Planning is another major component that can strengthen the entire DevOps process. Apart from the standard project planning, it is crucial to establish a strong collaboration between the business and the team. Once the KPIs are decided, it is essential to implement them around software architectures, languages and other frameworks.

Collaboration

A culture enriched with joint effort enables multi-functional engagements and shared responsibilities avoiding silos between Dev, Ops, and QA. Collaborating tools such as Slack, Yammer, and Chanty help the teams to communicate and cooperate between departments. In addition, the collaborative culture enables the teams to monitor the established Key Performance Indicators (KPIs) and ensure each phase runs smoothly throughout the process.

Tools and Automation

Integrating a tool system to collaborate across development helps provide seamless operations. Capture requests and feedback, integrate survey platforms, provide customer and real-time feedback, and spot the gaps and issues among teams are some significant benefits you can gain by integrating a tool system.

Sourcing and Microservices

It is essential to develop heterogeneous applications that include various languages, technologies, and other components. This helps to develop products quickly with higher flexibility as the industry is fast moving and needs to have adaptations with the latest technology. Moreover, many software companies use open-source packages due to several reasons, such as easy customization, lower costs, enhanced developer productivity etc.

Microservices are another aspect that software companies use over monolithic architecture. It can break down massive software projects into independent modules and define specific tasks to communicate through simple APIs. Furthermore, it can rectify errors independently and deploy them quickly without affecting the entire application. Overall, microservices result in increased agility, scalability, and reliability.

Improvements, Integrations, and Testing

To ensure continuous integration, software version management (SVM) is used to manage all source code changes and versions of code image changes used by the build process. Typically, these are managed in a single trunk or integration branch of the code. The system is engineered in a way where the resources are always sufficient to execute a build. Continuous integration practices ensure resources for a build are available on-demand and are fast enough to complete incremental builds in less than an hour.

The team works collaboratively for continuous testing and solves defects quickly and effectively, eliminating long delays. Software teams use new unit tests, functional regression, release regression, release performance, blue/green testing methods, and A/B tests depending on the specific software change and predefined criteria.

Continuous Monitoring and Security

To identify highest-priority problems, loggin and proactive systems are used by DevOps teams. They produce snapshots and end results of each metric. KPIs are also automatically gathered and calculated here. These are available to any team member who subscribes to them, and these practices help identify the problems quickly and concentrate on areas that need improvement.

Every organization embraces security monitoring practices and security assurance automation. The security platforms typically functioned via APIs with proven version control practices and tools. The codes and keys are accessible to trusted users only with verified credentials to maintain high-security practices.

Distributing, Delivery, and Deployment

Delivery is another pillar in the DevOps pipeline where deliverable packages with the sufficient configuration and test data are packaged and prepared for deployment. Here, configuration management tools are used to manage information and these measurements are achieved, and deliverables will be pushed to the deployment. Deployment is determined according to predetermined metrics and usually takes less than a day to process.

Apart from the traditional placement of applications in Appstore/Playstore, the software can be distributed and delivered in other ways to bring more value to the business. Open source, API access, and pushing software to edge deployments are some of the few conventions where companies can be a part of the external developer ecosystem and generate new revenue.

DevOps pillars can strongly affect the entire software development process, benefiting with excellent outputs. At Fidenz, we ensure to follow these critical pillars of DevOps to build successful software products. The practices can give a comprehensive view of how to build a DevOps strategy for your business with shorter iterations, enhanced functions, and reduced risks.

Read More

Amazon's New Pet - Astro

Amazon's New Pet - Astro

Amazon’s new pet Astro is a part of its Day 1 Editions program, with limited availability. Astro is a $1000 worth invasion-only program with a robust system and numerous use cases. While many of these are related to security, remote care and easy access, the robot also plays a role in entertainment. It carries a little carrying tray, a USB port for extensions, and a periscope that can pop out to see the counters. Astro working with Alexa together is another plus point for all the existing Alexa users to try out a combo and enhance their user experience.

The first-generation tech piece is an impressive feat that has tremendous potential. Given below are the prominent highlighted use cases of Astro that can help to improve the day-to-day life of its users.

  1. Home Monitoring - Astro can be an autonomous home-security system that can wander around the house. The robot has the ability to patrol a home, detect unidentified people, and send alerts. When you turn on the ‘away mode’, Astro can take care of your premises, ensuring its safety, and send alerts when it hears sounds like glass breaking or similar.
  2. Reminders & Updates - Astro can check on behalf of you whether the back door is open, whether you have left the stove on, or to check why the dog is barking at midnight without you having to leave your bed.
  3. Remote Care - For anyone who needs remote care can ask Astri to set and deliver reminders. There is a ‘Drop In’ option to stay connected. Together with Alexa, Astro can make work easy for those who are differently-abled or have mobility challenges.
  4. Entertainment - “Astro beatbox” or “what’s your favorite animal?” are top items that Amazon suggests as potential use cases that Amazon indicates in terms of fun things that Astro can provide and be closer to users as a pet than a machine.

Anthony Robson, the principal product manager for robotic technologies and consumer robotics at Amazon, insisted on having some level of extensibility. He further states, ‘We’re going to learn so much about every home — and every home is going to be different and have different needs. We have customers working in their home offices on either side of the house, sending things to each other using their Astro. We are learning, we are listening, and we are adapting. We will extend Astro’s capabilities as we learn from customers’.

When it comes to the drawback or the things the team wasn’t able to prioritize for launch, Astro not being able to climb stairs and its speed can be taken as the most significant. However, this is because of the need to keep the product simple and handy from a practical perspective. Also, adding the features such as climbing stairs can make it more complex, thus increasing the costs.

Moreover, the developer toolkit for the Astro robot is on its way and has not been launched yet. Nevertheless, the comms team for Astro is excited about the potential of the robot as a comms and monitoring tool.

The ability to build incredibly capable robotics with cute, expressive faces and high user-friendliness as first-generation tech gives us the hope to experience more refined Astro robots in the future.

Read More

Selecting between PoCs, Prototypes, and MVPs.

Selecting between PoCs, Prototypes, and MVPs.

Many companies struggle to choose the aptest technique to validate their concept and choose between POC, Prototypes, and MVP. In our previous context, we discussed the definitions, applications, advantages, and use cases of these elements. You can find the link to the article here and peruse the write-up for a comprehensive understanding.

It is essential to know that it depends on the business idea or the end product and your target audience (B2B, or B2C, B2B2C); and you may need to use PoC, Prototype, MVP or a combination accordingly.

Idea validation using these concepts will ensure that your final product will enable you to achieve its ultimate goal.

A PoC can usually provide a direct response to whether the concept will be viable or not for the target audience. Idea feasibility will be measured here, and with the comeback, you can decide whether to proceed with the existing plan or not. Furthermore, a PoC can help convince your initial pre-seed investors that your concept can be implemented and is technically viable.

On the other hand, MVP enables companies to grasp information about the target user's experience and respond to the core business purpose of the application. The insights received from actual users helps to validate the overall objectives, identify the user pain points, and address the issues over time.

If you want to present how exactly your final product will look like, or manifest the main design elements, prototyping is the best way to give the big picture to the end user. It further helps to run multiple test areas while saving your resources. If you are looking for investors to work on your project, a tested prototype is the best way to demonstrate and pitch your product.

Should PoC, Prototype, and MVP be Throwaway Builds (Minimum Initial Investment)

It is always better to look at PoC and MVP as throwaway codes. If your business idea takes momentum and finds traction, it is vital to build everything from scratch with architecture and design to cope with it for the next 3 to 5 years.

For PoC, think of the least expensive way to implement. Typically, when developing a PoC, factors like  product scale, architecture, UI elements are not considered. Instead, the requirement is to check on technical feasibility and customer feedback on your new product idea or a particular feature.

With all things considered, your PoC will be a hardly scalable piece to turn out for something decent. Hence, it is better to consider it as a throwaway build.

In relation to prototyping, it can be either a throwaway or a part of your final user interface, depending on the model type you select. For example, you can use rapid throwaway prototypes to receive user feedback and discard it later. These models are used to validate the system functionalities and requirements. Hence, it needs to be removed as it does not add any advantage to the final UX/UI elements.

For MVP, you may have to build in a way that could cope up with the demand for the next 12 to 18 months (Not a rule of thumb, but empirically proven ). It is common to see startups control the growth without hurting long term plans to build the post MVP version. However, for the long run, it is essential to opt for a complete rewrite ensuring your final product can have flexibility, extensibility and adaptation with upcoming technology and supplementary changes.

A Guide to Choose from Poc, Prototype, and MVP

Exhibiting a decision matrix using a table. - includes questions and scores for users to choose the correct method for their products.

Check out the reference tables at the end of this article.

Decision Matrix

ParametersPOCPrototypeMVP
Use CaseFor Technology/Market/Behavior disruption (completely new idea, so need to prove a concept is viable to build)To verify user journeys and messaging in a solution are understood by the intended users. Save time and money. Could used to attract seed fundingGet actual users to use your solution to solve the identified problem. Evaluating your solution solves the problem in an acceptable manner. Gather feedback from users to improve upcoming versions of the solution. Aim to the initial target audience response
PurposeTo verify technical/market/behavioral assumptions before getting down to development. / To clarify which way to go with the development. Convince internal stakeholdersMake the application usable for its intended users. To assure that the end users could navigate and get the job done using the solution. It is the working model of several aspects of your product. Prototypes help make decisions about product development and reduce the no. of mistakes and waste.To prove, your solution is effectively solving a problem and it is effective enough for the customer to pay for solution.To get the minimum version of the product to the market
Form of implementationMost rudimentary implementation to prove the relevant disruption is viable to implementHigh or Low fidelity Wireframes/UI, users could navigate through different screens but nothing has been implementedUsable solution by its real user, just to solve the identified problem (nothing more, nothing less)
Target audienceInternal users (Decision makers about the project GO/NO GO)Specifically selected sample of target audience (real users). Should be able to access more than once to verify the prototypes (should be able to involve with iterative process of prototype building)Sample of target audience. Easily accessible, Give genuine feedback. Test the product with a pre-selected potential customer group
CostLess budget and is ideal to collect internal funding. Might have to invest on new tools and accessories.Much less cost to build the prototype compared to PoC or MVP. More time/resources spent here saves time/resource at the expensive development phaseNo compromise on quality as the end product would be used by real users. Cut the cost by reducing features, not the quality. Well-defined budgets and looks for investment
Human ResourcesRequires technical experts to develop the basic concept. Could involve tech related R&DLess technical resources as no coding / development is involved. Need to recruit testers, Iterative design processesHere you are developing the actual product (at a smaller scale with less features) So needs full technical expertise
Risk EvaluationPoC involves the highest risk or all. But lessen the risk in upcoming phases.Reduce the risk in terms of user satisfaction in product navigationReduce the risk of losing time and resources of the full scale development
User InteractionN/A since is its used internallyGives an overview to the end user how the end product will look like with basic elements and navigation. Highly interactive with users but without real functionality.Full user interaction. UI/UX, Key Functions and even feedback from users also a part of interaction
Apparent time to createIf you have several options or if you uncertain about the feasibility of the conceptWhen you are confident about your idea and needs to start and test the design processWhen you are positive about the idea and the design, and ready to launch it to the market
When to Show the investorsPre-seed / SeedPre-seed / SeedPre-seed, Seed, rarely for Round A
CashflowNegative (expenses only)Could leads to Positive cash flows from Investors (Seed level)Should lead to Positive cash flows from service revenues & Investors
Extended useCan be used to develop MVPOutput can be used to develop the solution. No waste. If the prototype consist of UI design, it could be used for the developmentCan be expanded and used for the full version of the product. You may have to throw away the code (Do not hesitate to do so)
What you should not do?Invest time/resources to make the PoC usable to others.Implement things that have been already proven Use placeholder content or graphics.
Train/Assist testers. Test how UI/UX work on real environment
Compromise on quality
Implement extra/supplementary  features
Outsource or in-house workAt this stage, you are working on an idea to check out its possibilities of turning it into reality. Hence, it is ideal to do in-house to ensure that your concept would not be revealed to third parties /competitors.Prototypes can be fully outsourced as they will be exposed to the public for test-run purposes.MVP can be done internally or with the contribution of a third party. A mixed team is preferred here to build up the product. Here, the expertise (outsource party) can help with the best techniques while the in-house team is conscious of the progress/development plan.

Final Take Away

Building a solid foundation is essential to deliver a successful software product. Your PoC, prototypes, and MVP will be your foundation for the process, with actual feedback. They will help you to iterate the product process and enhance the features to meet the user requirements or the ‘real-needs’.

However, software product development is not limited to paying attention only to the initial process but is involved with many crucial steps that need to be considered throughout the proceeding. With that note, the next phase of the development process will be discussed in future articles.

Read More

PoCs, MVPs, Prototypes & Throw Away Codebases for Software Product Development

PoCs, MVPs, Prototypes & Throw Away Codebases for Software Product Development

The development of a successful software product requires excellent preparation with a series of steps. Brainstorming, planning, incorporating ideas, designing, QA are a few actions that are involved with the proceeding of product development. Each step helps to validate the stability and the effectiveness of the final product, and hence it is crucial to give equal attention every step of the way.

This is the second of our series of articles where we look into the basic elements that every expertise considers before developing a comprehensive software product. If you would like to keep up from inception, check our first article using the link below.

Link to our first article – The Essential Guide to Software Product Development.

If you are involved in a startup that is based on a new software product, these articles can help you understand the basics of how to go about it in the most economical and methodical way.

Disclaimer

This is based on 20+ years of experience in software product development. After seeing projects succeed, fail, survive, happy clients, angry clients etc. Encountering a mix of positive and negative things has helped this article to chip in a balanced view. It will further assist to learn how to succeed or fail with minimum damages or minimize disasters.

Significance of Software Development for Businesses

Software products have become one of the crucial needs to enhance and upscale any business. Automation of processes through software development helps to cut downtime and manual techniques for a smooth operation.

Streamline of internal functions, improved client experiences, feature-rich additions to the market are some top-notch features of software products that have made it super consumer effective while growing its popularity in every industry.

Problem Analysis

When you boil it all down, you will notice that the initial step of software development is identifying the problem. In other words, the need for a software product comes with addressing a particular issue.

Identifying and addressing the problem will ensure that you have developed the right solution as a software product. However, it is also essential to reckon that the problem and the requirements can be transitory and are likely to change over time.

Looking into the end-users or the target market is another critical point here. While collecting brick by brick for the development process, it is essential to pick out where your final product is going to fall. This could be Business-to-Business (B2B), Business-to-consumer (B2C), Business-to-Business-to-Consumer (B2B2C), or an internal software product development.

Once you have identified the problem and where the final product falls, take notes and put it out in a writing document to present for a group of people or your team. This allows you to receive multiple perspectives and dig deeper to understand the root causes that affect and manifest the main problem.

Pinpointing the primary problem, connecting the contributing factors, identifying the affected people (Eg, project sponsor, customer, user, management), defying the scope of the solution, and recognizing the solution constraints helps to analyze the problem, understand the affected areas and address them accordingly.

Idea Validation

The ultimate goal of idea validation is gathering evidence that your project will end with a paying customer or increase efficiency (to save time or cost). It helps to see the viability of your concept and how it will work in the real world.

Idea validation helps to reduce risks, speed up delivery and minimize costs. Below are a few questions to analyze the demand for your idea or to determine what the final product will achieve.

  1. Are you targeting the right audience with the correct problems?
  2. Can the final product help customers/users get their jobs done?
  3. How often do they need to use the product?
  4. Can your app solve a problem in a new way? Or is their innovation involved?


Setting up measurable and clear objectives is essential to determine how the idea will validate in the real world. In addition, formulating a hypothesis, developing a value proposition further enables you to get a clear answer.

PoC, Prototype, and  MVP

A substantial part of idea validation is covered by following three main ways; use of a Proof of Concept (POC), Prototypes, or a Minimum Viable Product (MVP).

To make it more comprehensible, check out these working definitions for PoC, Prototype, and MVP.

PoC- Works in a controlled environment with a set of preconditions. Typically, a PoC is operated by the technical team and cannot be used by the outside world. However, PoC helps to demonstrate the core challenges or the processes for a particular problem can be addressed using the solution proposed.

Prototype- Gives a clear picture of the design and the user journeys  of the application to make sure end-users could use the application conveniently. Users can mainly see the UI/UX aspects here but not the internal functionality.

MVP – A segment of the target audience will  use MVP to solve a real-world problem. An MVP is bound with limitations and may not have many features. But the core functionality can be used to benefit from the system.

Depending on the situation, software companies use PoC, Prototypes, MVP or a combination to validate and receive feedback for the final solution.

Proof Of Concept (POC)

A PoC helps to pursue ideas before approving them for further testing. It helps to identify the feasibility of the concept and identify potential issues that may affect the final product’s success. Using a PoC, you can determine whether the product can feasibly develop to solve the problem you are trying to solve.

For the most part, a PoC is developed internally in a controlled environment and cannot be assembled or changed. It is a skeleton of the final product with minimal features to test out and distinguish how it will work in the real world.

Given below are a few advantages of developing a PoC during software development.

  • It helps to choose the most appropriate technology for the development process.
  • Simplify and improve the software functionality
  • Receiving valuable feedback before building the actual product
  • Potential to get onboard clients before official product release
  • Avoid costly mistakes
  • Increases the chances of commercial success

Prototyping

A Prototype is an iterative process that is used to ascertain the UI/UX aspect and visualize your product to validate the user journeys. It will demonstrate the critical design elements and the user flows using wireframes and storyboards. It helps define the features that need to be included and makes up a model to expose the errors in studying and designing.

Typically, there are four prototyping models, namely, Rapid, Evolutionary, Incremental, and Extreme. In most cases, following a PoC, a prototype is used to obtain further details of your final product and to see how it looks and users would use the features in the end.

Identifying customer needs, enhancing product workflow with better understanding, identifying design and related mistakes are a few advantages of prototyping in your early product development process.

Most importantly, you can also use it as an opportunity to reach the users at an early stage and get their feedback before putting your product into the market.

Credential App

Reader App

Prototype of Credential App – Live demo

Prototype of Reader App – Live demo

Minimum Viable Product (MVP)

Typically, before releasing a full-fledged product, an MVP is used to collect feedback from early customers. The responses from the real world help developers to work on the versions and improve the product accordingly.

An MVP consists of the core features and the minimalist design that deploys the final product. The basic infrastructure is developed using the least possible expenditures and has certain limitations. Positive and negative feedback received from MVP help validate the idea of the final product and see the potentiality of its success. It can also be used to solve an existing problem or could be used to improve the efficiency (cut down of effort taken, time taken, or cost involved) of a task.

MVP introduces efficiency to a selected task (core problem your application solve), and there could be many other auxiliary features that could improve the efficiency of the same job. But with the MVP mindset, you will not try to include those complementary features in the solution you provide at the MVP stage. So, again, that’s why we call it MVP. Solve the intended problem, but nothing more, nothing less.

There are different types of MVP concepts that can be used based on the purpose. Software prototypes, product designs, concierge, landing pages, piecemeal, demo videos, and wizard of Oz are  some of the main ways the MVP concept is used. Dropbox, Amazon, Airbnb, and Facebook are a few well-known examples that started with the MVP technique.

Below are the key advantages of using MVP.

⦁ Avoid lengthy unnecessary work
⦁ Gain insights on product viability and usability
⦁ Saves project time and money
⦁ It gives clarity around the final product idea
⦁ Analyze market demand

When you disregard all non-essential features, that brings the time to market your product less and cost to develop your product less. These are the pillars of lean product development.

Choosing between POCs, Prototypes, and MVPS could be crucial to find the aptest solution for your business proposition. Furthermore, after considering all these essentials, you could decide on selecting them as throwaway codebase elements or not. Hence, our preceding context will discuss the guidelines and the necessities to choose between these elements.

We want to thank Chalinda Abeykoon for being a part of this effort and adding value to this article by sharing his insights and experience.

Stay tuned for our next article.

Read More
